The first AI PC.The Intel Apollo Lake platform is equipped with an ultra - ultra short focal length machine.
Optical technology is combined with touch technology, using 3D touch mode and camera recognition algorithm.
Desktop projection 15 inches (16:9), touch Angle 150 degrees and gesture recognition 120 degrees
New metal texture, humanized design, simple and easy to use, lightweight and portable.
Product Feature
Disruptive Innoation ,Experiential Design
First AI Computer
AI Computer touch machine
High Quality Metal Process
Main Specifications
Product Model AI Projection Computer
Projection tech DLP @ TI
Display Chip DMD RGB-LED
Brightness 220LM
Brightness Uniformity 80%
Contrast 600:01:00
Physical Resolution 1280*720
Compatiable Resolution More than 800*600
Projection Specification
Light Source Type RGB LED
Projection Ratio 0.39:1 (30" @266mm
Projection Type Offset axis 149% ultra short focus
Focusing Type Manual Regulation
Mainboard Specification
CPU Intel® Celeron® Processor N3450 2M Cache, up to 2.2 GHz
Intel® Pentium® Processor N4200 2M Cache, up to 2.5 GHz
Operation Mode Desktop touch and stroke ( Support 10 point touch)
RAM 4GB LPDDR3 Onbaord Memory (Optional 8GB )
Memory 64GB eMMC Onboard ( Optional 128GB)
Graphical Intel® HD Graphics 505 (200Mhz-750Mhz )
WIFI Built-in 3165D2WG Support 2.4G -5G Double Band
Bluetooth Bluetooth 4.0
AR Identify Built-in 500W wide Angle Camera
Mic Built-in Microphone
Audio Built-in single 2W speaker
Fan Bulil-in 5V/2W Fan
Display Proportion 16:09
Refresh Rate 60HZ
Battery Built-in 7.4V=8000mAh
I/O Port
USB 2*USB3.0
HDMI 1*HDMI Port
earphone 1*3.5mm earphone
Power 1*5.5mm DC-IN
Other
Size 207.5mm*115.5mm*48mm
Weight 1.12Kg
Charger INPUT:220/50Hz OUTPUT:19V/3.42A
Accessories White Projection Film/Touch Pen
